18MM PYROSTOP30-20 | Fire Rated Glass

£734.71 per m2

  • Fire Insulation 30 mins
  • Fire Integrity 30 mins
  • Internal only
  • Impact 1(b)1
Panels over 2.5m2 must be Priced as over size panels and may incur extra costs. please contact us.
Laminated Glass - Minimum Charge 0.5m2 (per panel)
Toughened / Float Glass - Minimum Charge 0.3m2(per panel)
Fire Insulation (Mins): 30
Fire Integrity (Mins): 30
Installation Uses: Timber
  • Timber
Environmental Uses: Internal
Glass Thickness: 18
Impact Class: 1(c)1
SKU: 18mm Pyrostop 30-20 external
Total Area (sq m)
Product Price

Description

Enhanced Safety Meets Elegance: Pilkington Pyrostop 30-20-18mm from Buyglass.Co

Buyglass.Co proudly presents the Pilkington Pyrostop 30-20-18mm Glass. This superior glass solution offers excellent fire protection while maintaining the aesthetic appeal and brightness of your spaces.

Top-tier Fire Resistance

The Pilkington Pyrostop 30-20-18mm Glass adheres to the strictest fire protection standards, holding an impressive EI classification. This glass provides both Integrity (E) and Insulation (I) for a duration of 30 minutes (EI30), forming a robust defence against the devastating effects of fire.

Its excellent Integrity Rating ensures the glass will stay in place during a fire, halting the spread of flames and hot gases. Meanwhile, the remarkable Insulation Rating significantly limits the transmission of radiant and conductive heat, allowing for a safe evacuation and facilitating firefighting efforts.

Versatility for Various Applications

Available at Buyglass.Co, the Pilkington Pyrostop 30-20-18mm Glass is a versatile choice for both commercial and residential properties. It’s perfect for internal and external doors, partitions, facades, and fire escape routes. Its reliable fire-resistant attributes make it a preferred choice for high-risk areas such as commercial kitchens, data centers, and laboratories.

Design without Compromise

Despite its strong fire protection properties, the Pilkington Pyrostop 30-20-18mm Glass provides high levels of transparency, ensuring your spaces remain bright, inviting, and safe.

Choose Buyglass.Co for Superior Safety

Invest in Pilkington Pyrostop 30-20-18mm Glass from Buyglass.Co and create a secure, luminous environment. Your safety is our utmost priority, and we don’t compromise on style. View the product here and make a wise investment in a safer and brighter future today.

Datasheet

Pyrostop Brochure

Pyrostop Certificate of Approval

Installation Instructions

Technical Information

NPD = NO PERFORMANCE DETERMINED. NOTIFIED PRODUCTION CONTROL CERTIFICATION BODY NUMBER 1121, 0432, 0757, 1750, 1234, 1004, 1680, 2509, 1314, 1488, 1812, 0833, 0402

(Note: The above links redirect to the reference site provided and serve as placeholders for actual product image links.)





Additional information

Weight 45 kg
Fire Insulation (Mins)

Fire Integrity (Mins)

Brand

Pyrostop

Environmental Uses

Internal

Sound Reduction

Glass Thickness

Installation Uses

,

Impact Class

1(c)1

Fire-Rated FAQ


Fire rated glass is often required by UK building regulations in certain areas to improve fire safety, protect people, and limit property damage. It can also offer peace of mind.

There are several types of fire rated glass, including:

  • Intumescent glass: Expands when heated, creating a protective barrier.
  • Wired glass: Contains a wire mesh that holds the glass together if it cracks.
  • Gel-filled glass: Contains a clear gel that turns opaque when heated.
  • Ceramic glass: Made from high-temperature ceramics for excellent fire resistance.

Yes, UK building regulations often require fire rated glass in specific places, like fire doors, fire exits, protected stairwells, and compartment walls. The exact requirements depend on the building’s purpose and layout.

Pyroguard is a leading manufacturer of fire-rated glass known for its high-quality products and innovative solutions. Their range includes various fire-resistant glass types with different performance characteristics, suitable for various applications in both commercial and residential settings. Pyroguard prioritises safety and performance, offering reliable protection against fire and smoke spread. They also provide technical support and resources to assist with product selection and installation. You can explore their range of products on the Pyroguard website.

Additionally, we at BuyGlass.co offer a selection of Pyroguard products, such as the 19mm Pyroguard EI60, providing excellent fire resistance and insulation for up to 60 minutes.

If you’re looking for a reputable and trusted brand with a proven track record in fire safety, Pyroguard is a solid choice for your project.

Saint-Gobain Contraflam® offers a comprehensive range of fire ratings, from E30 to EI120, catering to different applications and building regulations. You can explore the various fire rating options and technical specifications on the Contraflam® product page on the Saint-Gobain website.

Saint-Gobain Contraflam® is renowned for its versatility and aesthetic appeal. It offers a wide range of fire ratings and configurations, including clear, tinted, and patterned options, making it suitable for various architectural styles and applications. Discover the benefits of Contraflam® on the Saint-Gobain website.

Pilkington Pyrostop® is a leading brand of fire-rated glass known for its high performance and extensive range of options. It consistently meets or exceeds industry standards and offers excellent fire resistance, making it a popular choice for both commercial and residential projects. You can learn more about Pilkington Pyrostop® on their website.

You can buy high-quality fire rated glass from BuyGlass.co. We offer a wide selection of fire rated glass products, expert advice, and advice on professional installation services across the UK.

Integrity means the glass’s ability to contain flames and smoke, while insulation means its ability to reduce heat transfer. Some fire rated glass offers both integrity and insulation (Ei), while others may only provide integrity (E).

Fire rated glass has a long lifespan, often over 20 years with proper care and maintenance. Regular checks are recommended to ensure it stays in good condition and keeps its fire resistance.

Fire rated glass typically needs minimal maintenance, similar to regular glass. It’s important to clean it with non-abrasive materials and avoid harsh chemicals that could damage the surface or coatings.

Yes, fire rated glass is usually pricier than regular glass due to the special materials and manufacturing processes. However, it offers superior protection and can be a worthwhile investment for safety and peace of mind.

Some types of fire rated glass, especially those with insulation, can greatly reduce heat transfer, making them suitable for applications where thermal insulation is important.

Fire rated glass comes in various sizes to suit your needs, however, it is important that you contact us before ordering to ensure that your made-to-measure fire rated glass is within the certification criteria.

The required thickness of fire rated glass depends on the specific fire rating and where it will be used. Regulations set minimum thicknesses for different fire ratings. Ask our experts for help choosing the right thickness for your project.

No, fire rated glass shouldn’t be cut after manufacture as it can affect its fire resistance. It’s important to order the correct size for your needs.

While not always mandatory in homes, fire rated glass is recommended for areas like internal doors leading to garages or high-risk rooms. It can enhance fire safety and provide peace of mind.

The cost of fire rated glass varies depending on several factors, including the type of glass, size, thickness, fire rating, and extra features like insulation or soundproofing. Contact us for a tailored quote.

Fire ratings like E30 show the time (in minutes) the glass can resist fire while maintaining integrity (E) and/or insulation (i). For example, E30 means the glass can hold back flames and smoke for 30 minutes.

UK fire rated glass regulations are mainly outlined in Approved Document B (fire safety) of the Building Regulations. These regulations specify where fire-resistant glazing is needed and the required fire ratings.

Fire rated glass is made with special materials or construction methods that help it stay strong in extreme heat. Some types also insulate, reducing heat transfer.

Fire rated glass is a special type of safety glass designed to withstand high temperatures and stop fire and smoke from spreading for a set amount of time. It’s essential for protecting escape routes and containing fires.

Understanding Fire Rated Glass: A Comprehensive Guide

Fire rated glass is a crucial component in modern building design, providing both aesthetic appeal and essential safety features. In this blog post, we will explore the various aspects of fire rated glass, including its types, applications, and the benefits it offers for enhancing fire safety in buildings. We will also discuss the fire rated glass price, the leading fire rated glass manufacturers, and the key considerations for fire rated glass installation.

What is Fire Rated Glass?

Fire rated glass, also known as fire resistant glass or fireproof glass, is specially designed to withstand high temperatures and prevent the spread of flames and smoke during a fire. This type of glass is integral to fire safety systems, providing vital barriers in buildings to contain and control fire.

Types of Fire Rated Glass

There are several types of fire rated glass, each with specific characteristics and applications:

Applications of Fire Rated Glass

Fire rated glass is versatile and can be used in various applications, including:

Benefits of Fire Rated Glass

Using fire rated glass in building design offers numerous benefits:

  • Enhanced Safety: Prevents the spread of fire and smoke, protecting lives and property.
  • Aesthetic Appeal: Maintains the visual openness and design integrity of modern buildings.
  • Compliance: Meets stringent fire safety regulations and standards.
  • Versatility: Suitable for a wide range of applications, from windows and doors to partitions and panels.

Different Fire Ratings and How They Work

Fire rated glass comes with various fire ratings, which indicate the duration the glass can withstand fire exposure. These ratings are crucial for determining the appropriate use cases for the glass. The ratings are usually expressed in minutes, such as 30, 60, 90, and 120 minutes.

  • 30-Minute Fire Rating: This rating means the glass can withstand fire exposure for 30 minutes. It is typically used in fire rated window glass and fire rated glass doors in residential and low-risk commercial applications.
  • 60-Minute Fire Rating: Glass with a 60-minute rating offers an hour of protection and is suitable for higher-risk areas such as stairwells, corridors, and fire rated glass partitions in commercial buildings.
  • 90-Minute Fire Rating: This rating is used in areas that require extended protection, such as large commercial buildings, schools, and hospitals. It is ideal for fire resistant glazing systems that need to provide a higher level of safety.
  • 120-Minute Fire Rating: Providing up to two hours of protection, this glass is used in high-risk areas where the potential for prolonged fire exposure exists. It is suitable for critical infrastructure and buildings with stringent fire safety requirements.

Fire Rated Glass Price

The price of fire rated glass varies depending on factors such as thickness, size, and the specific fire rating required. It is important to consult with fire rated glass manufacturers and suppliers to get accurate pricing and ensure you are getting the best product for your needs.

Leading Fire Rated Glass Manufacturers and Suppliers

When selecting fire rated glass, it is crucial to choose reliable manufacturers and suppliers who offer certified products. Some of the top sources include:

Fire Glass Certification

Ensuring that your fire rated glass is properly certified is crucial for compliance and safety. Certification verifies that the glass meets rigorous standards and has been tested for fire resistance and durability.

Fire Rated Glass Installation

Proper installation is essential for the effectiveness of fire rated glass. It is recommended to use professional installers who are experienced with fire rated glazing systems. This ensures that the glass performs as intended in the event of a fire.

Fire Safety Glass Requirements

Understanding the specific requirements for fire safety glass in your building is critical. These requirements can vary depending on the building type, location, and local fire safety regulations. Consulting with experts in fireproof glazing can help you navigate these requirements and ensure compliance.

Conclusion

Fire rated glass plays a vital role in modern building safety, offering both protection and aesthetic benefits. Whether you are looking to install fire resistant glass for windows, doors, or partitions, understanding the types, benefits, and installation requirements is essential. By choosing certified products and professional installation, you can ensure the highest level of fire safety in your building.

For more information and to explore a wide range of fire rated glass options, visit BuyGlass.co.
